Reflow Ovens
We provide reflow oven for all types of PCBA assembly, from prototyping to high-volume. Accurate, high quality full convection reflow oven for PCBA electronics assembly
The reflow oven is a critical piece of equipment in the modern electronics manufacturing (SMT) process.
Its core function is to create reliable electrical interconnections. Through a precisely controlled heating process, it melts the solder paste previously applied to the PCB pads, securely welding the pins or terminals of the surface-mounted components to the PCB.A standard reflow process is typically divided into four key stages: the Preheat Zone, Soak Zone (or Heating Zone), Reflow Zone (or Welding Zone), and Cooling Zone. S&M Chuxin’s VS Series reflow ovens are engineered to ensure every solder joint is perfect and reliable through superior thermal uniformity, efficient heat compensation, and intelligent temperature control
Understanding the Heart of SMT
A reflow oven is a key machine in the Surface Mount Technology (SMT) line. Its primary job is to use a precise heating and cooling sequence, known as a “thermal profile,” to melt solder paste. This process creates strong, reliable electrical bonds between electronic components and the Printed Circuit Board (PCB).
The Four Critical Stages of the Reflow Soldering Profile
This thermal profile is divided into four distinct zones, each with a specific function.
1. Preheat Zone
Purpose: Gradually raises the assembly’s temperature.
Key Actions:
Prevents thermal shock (cracking) to sensitive components.
Safely evaporates volatile solvents from the solder paste.
2. Soak (Thermal Stabilization) Zone
Purpose: Equalizes the temperature across the entire board.
Key Actions:
Ensures large and small components reach a uniform temperature.
Activates the flux, which cleans the surfaces for soldering.
Learn More: Un ghid aprofundat al profilului de reflow
3. Reflow (Time Above Liquidus) Zone
Purpose: The peak temperature stage where soldering happens.
Key Actions:
The oven temperature rises above the solder’s melting point.
Molten solder “wets” the component leads and PCB pads, forming the permanent joint.
Learn More: Cum să setați un profil de temperatură al cuptorului Reflow pentru o lipire mai bună
4. Cooling Zone
Purpose: Rapidly and in a controlled manner, cools the assembly to solidify the solder.
Key Actions:
A fast cooling rate (e.g., 3-6°C per second) is critical for a strong, fine-grain joint structure.
S&M ovens use high-efficiency top and bottom convection for optimal cooling.
Learn More: Un ghid cuprinzător pentru zona de răcire a cuptorului Reflow
S&M Reflow Soldering Solutions (VS Series)
Aspectul tehnic
Echipa noastră
Asigurarea calității
Asigurați conformitatea cu reglementările și îndepliniți/depășiți standardele de calitate pentru a livra produse în mod eficient.
Service to the Best: Stabilirea clientului
satisfacția față de serviciile noastre este standardul
conceptul de testare a calității serviciului nostru.
Standard ridicat de calitate a serviciilor
- Standardizarea proceselor de servicii
- Formare profesională periodică
- Semnarea ordinului de serviciu la fața locului
- Implementarea unui mecanism de punctare a clienților
- Răspuns în termen de 2 ore
- Serviciu 24h*7
Controlul calității
- Raport de inspecție
- Raport de expediere
- Lista de piese
