Conveyor / Inspection Conveyor

Product number:PTB/PTC

Features

On the conveyor base is equipped with an active work table, document signage, lighting fixtures.
The lighting brightness, working height, etc. are user-friendly and the operation is more efficient, convenient and practical.
Green flat imported anti-static transmission belt, durable, easy to replace.
Sheet metal weights the structure, the overall stability, not easy to shift.
Track entrance and exit independent installation guide extension block for easy adjustment and replacement.
PLC control system, through SMEMA communication mode.

Optional Features

Two-segment transmission or multiple-segment transmission(minimum 0.5m in length);two independent adjustments of width;
Install cooling fan,block cylinder,platform,dust cover and other additional configuration;
Special program requirements such as cooperation with the scanner,AOl and NG/OK communication function;
Optional transmission speed:50~250mm,50~350mm, 50~460mm,50~510mm.

Description	Used for connection or operator inspection between SMT equipment
Conveyor speed	0.5-20 Meter/Min or specified by customer
Power supply and electrical load	Single-phase 220V AC Up to 300VA
Board thickness	Min. 0.6mm

Model	PTB-460	PTC-460	PTB-D300
Circuit board effective size(mm)	80(L)×50(W)-510(L)×460(W)	80(L)×50(W)-510(L)×460(W)	Maximum width of both sides 300
Transmission height(mm)	900±20(mm)	900±20(mm)	900±20(mm)
Dimensions(mm)	500~2500(L)	500~2500(L)	500~1500(L)
	630(w)	740(w)	750(w)
	900H (The height of the illuminator is 1800mm）	900H (The height of the illuminator is 1800mm）	900H (The height of the illuminator is 1800mm）
weight (kg)	50-130(kg)	65-170(kg)	70-145(kg)
